The table below lists the Status – Hall Call Status, CPLD Status, Virtual Inputs, and DIP Status
menu structures.
Table 13: Status – Hall Call Status, CPLD Status, Virtual Inputs, and DIP Status Menu Structures
Menu
Description
Status
Hall Call Status
Shows the status of hall calls
DAD Status
Shows the status of DAD unit
Clock
View current clock setting on the system
CPLD Status
Shows the status of CPLDs
Load Weigher Status
Shows the status of the Load Weigher device
E-Power Status
Shows the status of emergency power
EMS Status
Shows the status of emergency medical service
Virtual Inputs
Shows the status of all inputs via remote access
DIP Status
Shows the status of the DIP switches
Door Status (F)
Shows the status of a front door
Door Status (R)
Shows the status of a rear door
Hall Call Status
Up Calls
Shows list of latched up hall calls per car
Down Calls
Shows list of latched down hall calls per car
CPLD Status
MR CPLD
Shows MR current CPLD version, activity, and faults
CT CPLD
Shows CT current CPLD version, activity, and faults
COP CPLD
Shows COP current CPLD version, activity, and faults
Virtual Inputs
Car Call Security
Shows status of car call security map set remotely
Hall Call Security
Shows status of hall call security map set remotely
Virtual Inputs
Shows the status of variety of inputs set remotely by remote
monitoring system
Recall Input
Shows the recall floor and door that opens when remote recall to
floor input is asserted
Door Command Landing
Shows the status of a door to a designated landing
DIP Status
MR DIP
Shows the status of MR DIP switches that are on
CT DIP
Shows the status of CT DIP switches that are on
COP DIP
Shows the status of COP DIP switches that are on
