0A-1 General Information:
General In formation
General Information
General Description
Symbols
B823H10101001
Listed in the table below are the symbols indicating instructions and other information necessary for servicing.
The meaning of each symbol is also included in the table.
Abbreviations
B823H10101002
A:
ABDC: After Bottom Dead Center
AC: Alternating Current
ACL: Air Cleaner, Air Cleaner Box
API: American Petroleum Institute
ATDC: After Top Dead Center
ATM Pressure: Atmospheric Pressure, Atmospheric
Pressure Sensor (APS, AP Sensor)
A/F: Air Fuel Mixture
B:
BBDC: Before Bottom Dead Center
BTDC: Before Top Dead Center
B+: Battery Positive Voltage
BARO: Barometric pressure (Atmospheric pressure)
C:
CKP Sensor: Crankshaft Position Sensor (CKPS)
CKT: Circuit
CLP Switch: Clutch Lever Position Switch (Clutch
Switch)
CMP Sensor: Camshaft Position Sensor (CMPS)
CO: Carbon Monoxide
CPU: Central Processing Unit
D:
DC: Direct Current
DMC: Dealer Mode Coupler
DOHC: Double Over Head Camshaft
DRL: Daytime Running Light
DTC: Diagnostic Trouble code
E:
ECM: Engine Control Module Engine Control Unit
(ECU) (FI Control Unit)
ECT Sensor: Engine Coolant Temperature Sensor
(ECTS)
Water Temp. Sensor (WTS)
EVAP: Evaporative Emission
EXC System: Exhaust Control System (EXCS)
Symbol Definition
Torque control required.
Data beside it indicate specified torque.
Apply oil.
Use engine oil unless otherwise specified.
Apply molybdenum oil solution.
(Mixture of engine oil and SUZUKl MOLY PASTE in a ratio of 1:1).
Apply SUZUKI SUPER GREASE “A” or equivalent.
99000-25010
Apply SUZUKI MOLY PASTE or equivalent.
99000-25140
Apply SUZUKI SILICONE GREASE or equivalent.
99000-25100
Apply SUZUKI BOND “1207B” or equivalent.
99000-31140
Apply THREAD LOCK SUPER “1303” or equivalent.
99000-32030
Apply THREAD LOCK SUPER “1322” or equivalent.
99000-32110
Apply THREAD LOCK SUPER “1360” or equivalent.
99000-32130
Use engine coolant or equivalent.
99000-99032-11X
Use fork oil or equivalent.
99000-99044-L01
Apply MUFFLER SEAL LOCTITE “5920” (commercially available) or equivalent.
Apply or use brake fluid.
Use special tool.
Do not reuse.
Note on reassembly.
