Charging System: 1J-15
Specifications
Service Data
B823H11A07001
Electrical
Unit: mm
CAUTION
!
Never use anything except the specified battery.
Tightening Torque Specifications
B823H11A07002
NOTE
The specified tightening torque is also described in the following.
“Regulator / Rectifier Construction (Page 1J-9)”
Reference:
For the tightening torque of fastener not specified in this section, refer to “Tightening Torque List in Section 0C
(Page 0C-9)”.
Item Specification Note
Generator coil resistance 0.2 – 0.7 :
Generator maximum output Approx. 400 W at 5 000 r/min
Generator no-load voltage (When
engine is cold)
70 V (AC) and more at 5 000 r/min
Regulated voltage 13.5 – 15.5 V at 5 000 r/min
Battery
Type designation YTX12-BS
Capacity 12 V 36 kC (10 Ah)/10 HR
Standard electrolyte S.G. 1.320 at 20 qC (68 qF)
Fastening part
Tightening torque
Note
Nmkgf-mlb-ft
Generator stator set bolt 11 1.1 8.0 )(Page 1J-7)
CKP sensor mounting bolt 6.5 0.65 4.7 )(Page 1J-7)
Generator rotor bolt 120 12.0 87.0 )(Page 1J-8)
