Rear Brakes: 4C-8
Specifications
Service Data
B823H14307001
Brake
Unit: mm (in)
Tightening Torque Specifications
B823H14307002
NOTE
The specified tightening torque is also described in the following.
“Rear Brake Components (Page 4C-1)”
Reference:
For the tightening torque of fastener not specified in this section, refer to “Tightening Torque List in Section 0C
(Page 0C-9)”.
Item Standard Limit
Brake disc thickness Rear 5.3 – 5.7 (0.21 – 0.22) 5.0 (0.20)
Brake disc runout — 0.30 (0.012)
Brake caliper cylinder bore Rear 38.180 – 38.256 (1.5031 – 1.5061) —
Brake caliper piston diam. Rear 38.098 – 38.148 (1.4999 – 1.5019) —
Brake fluid type DOT 4 —
Fastening part
Tightening torque
Note
Nmkgf-mlb-ft
Rear brake caliper mounting bolt 17 1.7 12.5 )(Page 4C-3)
Rear brake pad mounting pin 15 1.5 11.0 )(Page 4C-3)
Brake hose union bolt 23 2.3 16.5 )(Page 4C-3)
Rear brake caliper sliding pin 33 3.3 24.0 )(Page 4C-5)
Brake disc bolt (Rear) 35 3.5 25.5 )(Page 4C-7)
