6B-1 Steering / Handlebar:
Steeri ng
Steering / Handlebar
Repair Instructions
Handlebar Components
B823H16206001
1
1
5
6
7
8
9
4
4
2
(b)
(b)
3
(c)
FWD
FWD
FWD
FW
D
(a)
(a)
“A”
I823H1620029-07
(c)
5
6
7
I823H1620030-04
1. Throttle grip 6. Handle balancer expander : 23 Nm (2.3 kgf-m, 16.5 lb-ft)
2. Handlebars 7. Handlebar balancer : 10 Nm (1.0 kgf-m, 7.0 lb-ft)
3. Handlebar holder (Upper) 8. Right handlebar switch box : 5.5 Nm (0.55 kgf-m, 4.0 lb-ft)
4. Grip rubber 9. Left handlebar switch box : Apply thread lock to the thread part.
5. Handle expander “A”: Apply handle grip bond.
