4B-1 Front Brakes:
Brake
Front Brakes
Repair Instructions
Front Brake Components
B823H14206001
(a)
2
4
3
2
4
3
3
1
(b)
(c)
(d)
(e)
5
6
(f)
FWD
FWD
7
I823H1420023-07
1. O-ring 7. Brake pad spring : 23 Nm (2.3 kgf-m, 16.5 lb-ft)
2. Piston seal : 27 Nm (2.7 kgf-m, 19.5 lb-ft) : Apply thread lock to the thread part.
3. Dust seal : 6 Nm (0.6 kgf-m, 4.5 lb-ft) : Apply brake fluid.
4. Piston : 17 Nm (1.7 kgf-m, 12.5 lb-ft) : Do not reuse.
5. Front brake pad set : 2.5 Nm (0.25 kgf-m, 1.8 lb-ft)
6. Front brake disc : 39 Nm (3.9 kgf-m, 28.0 lb-ft)
