1E-2 Engine Lubrication System:
#4 PISTON
COOLING
OIL JET
#3 PISTON
COOLING
OIL JET
#2 PISTON
COOLING
OIL JET
CAMSHAFT JOURNALS,
CAMFACES AND TAPPETS
CAMSHAFT JOURNALS,
CAMFACES AND TAPPETS
INTAKE CAMSHAFT
HOUSING
INTAKE CAMSHAFT
RH-BEARING AND
CAM SPROCKET
OIL PIPE
EXHAUST CAMSHAFT
HOUSING
RH-BEARING AND
CAM SPROCKET
CYLINDER HEAD
OIL HOSE
CAM DRIVE CHAIN
SUB GALLERY
STATER
CLUTCH
#1 PISTON
COOLING
OIL JET
OIL PIPE
#1 PISTON AND
CYLINDER WALL
#2 PISTON AND
CYLINDER WALL
#3 PISTON AND
CYLINDER WALL
#4 PISTON AND
CYLINDER WALL
#1 CRANKSHAFT
PIN BEARING
#2 CRANKSHAFT
PIN BEARING
#3 CRANKSHAFT
PIN BEARING
OIL JET
#1 CRANKSHAFT
JOURNAL BEARING
#2 CRANKSHAFT
JOURNAL BEARING
#3 CRANKSHAFT
JOURNAL BEARING
#4 CRANKSHAFT
JOURNAL BEARING
#5 CRANKSHAFT
JOURNAL BEARING
GENERATOR
MAIN GALLERY
OIL JET
OIL JET ORIFICE
BALANCER
SHAFT
DRIVESHAFT
RIGHT-SIDE
BEARING
OIL FILTER
COUNTERSHAFT
LEFT-SIDE
BEARING
ORIFICE
CLUTCH PUSH
PIECE
OIL PUMP
CLUTCH PLATES
OIL STRAINER
EXHAUST CAMSHAFT
#4 CRANKSHAFT
PIN BEARING
DRIVESHAFT
GEARS AND
BUSHINGS
PRIMARY DRIVEN
GEAR BEARING
OIL PAN
OIL PRESSURE
SWITCH
OIL PRESSURE
REGULATOR
CAM CHAIN
TENSION
ADJUSTER
COUNTERSHAFT
GEARS AND
BUSHINGS
OIL COOLER
OIL HOSE
I823H1150001-04
