Drive Chain / Drive Train / Drive Shaft: 3A-11
Specifications
Service Data
B823H13107001
Drive Train
Unit: mm (in)
Tightening Torque Specifications
B823H13107002
NOTE
The specified tightening torque is also described in the following.
“Drive Chain Related Components (Page 3A-1)”
Reference:
For the tightening torque of fastener not specified in this section, refer to “Tightening Torque List in Section 0C
(Page 0C-9)”.
Special Tools and Equipment
Recommended Service Material
B823H13108001
NOTE
Required service material is also described in the following.
“Drive Chain Related Components (Page 3A-1)”
Item Standard Limit
Final reduction ratio 2.388 (43/18) —
Drive chain
Type RK GB50GSVZ4 —
Links 118 links —
20-pitch
length
— 319.4 (12.57)
Drive chain slack (on center stand) 20 – 30 (0.8 – 1.2) —
Gearshift lever height 55 – 65 (2.2 – 2.6) —
Fastening part
Tightening torque
Note
Nmkgf-mlb-ft
Engine sprocket nut 145 14.5 105.0 )(Page 3A-3)
Speed sensor rotor bolt 28 2.8 20.0 )(Page 3A-3)
Speed sensor bolt 6.5 0.65 4.7 )(Page 3A-3)
Rear sprocket nut 60 6.0 43.5 )(Page 3A-4)
Material SUZUKI recommended product or Specification Note
Grease SUZUKI SUPER GREASE A or
equivalent
P/No.: 99000–25010 )(Page 3A-3) / )(Page 3A-
4) / )(Page 3A-6) /
)(Page 3A-6)
Thread lock cement THREAD LOCK CEMENT SUPER
1322 or equivalent
P/No.: 99000–32110 )(Page 3A-3)
To Next Page
