Exterior Parts: 9D-18
Frame Body Cover
Removal
Remove the frame body cover(-s) (1) (LH & RH).
Installation
Install the frame body cover(-s) in the reverse order of
removal.
Front Fender
Removal
Refer to “Front Fork Removal and Installation in Section
2B (Page 2B-2)”.
Installation
Refer to “Front Fork Removal and Installation in Section
2B (Page 2B-2)”.
Rear Fender
Removal
Refer to “Seat Lock Cable Routing Diagram (Page 9D-
1)”.
Installation
Refer to “Rear Fender Construction (Page 9D-11)”.
Specifications
Tightening Torque Specifications
B823H19407001
NOTE
The specified tightening torque is also described in the following.
“Frame Body Cover Construction (Page 9D-4)”
Reference:
For the tightening torque of fastener not specified in this section, refer to “Tightening Torque List in Section 0C
(Page 0C-9)”.
“A”: Hooking point
1
“A”
I823H1160003-01
To Next Page
