Wheels and Tires: 2D-19
Specifications
Service Data
B823H12407001
Wheel
Unit: mm (in)
Tire
Tightening Torque Specifications
B823H12407002
NOTE
The specified tightening torque is also described in the following.
“Front Wheel Components (Page 2D-2)”
“Front Wheel Assembly Construction (Page 2D-3)”
“Rear Wheel Components (Page 2D-9)”
“Rear Wheel Assembly Construction (Page 2D-10)”
Reference:
For the tightening torque of fastener not specified in this section, refer to “Tightening Torque List in Section 0C
(Page 0C-9)”.
Item Standard Limit
Wheel rim runout
Axial
— 2.0 (0.08)
Radial
Wheel rim size
Front 17 M/C x MT 3.50 —
Rear 17 M/C x MT 6.00 —
Wheel axle runout
Front
— 0.25 (0.010)
Rear
Item Standard Limit
Cold inflation tire pressure
(Solo riding)
Front 250 kPa (2.50 kgf/cm
2
, 36 psi) —
Rear 290 kPa (2.90 kgf/cm
2
, 42 psi) —
Cold inflation tire pressure
(Dual riding)
Front 250 kPa (2.50 kgf/cm
2
, 36 psi) —
Rear 290 kPa (2.90 kgf/cm
2
, 42 psi) —
Tire size
Front 120/70 ZR17 M/C (58 W) —
Rear 200/50 ZR17 M/C (75 W) —
Tire type
Front DUNLOP: Qualifier MT —
Rear DUNLOP: Qualifier NK —
Tire tread depth
(Recommended depth)
Front — 1.6 mm (0.06 in)
Rear — 2.0 mm (0.08 in)
Fastening part
Tightening torque
Note
Nmkgf-mlb-ft
Front brake caliper mounting bolt 39 3.9 28.0 )(Page 2D-5)
Front axle bolt 100 10.0 72.5 )(Page 2D-5)
Front axle pinch bolt
23 2.3 16.5
)(Page 2D-5) /
)(Page 2D-5)
Rear axle nut 100 10.0 72.5 )(Page 2D-11)
To Next Page
