Ignition System: 1H-3
Schematic and Routing Diagram
Ignition System Diagram
B823H11802001
Refer to “Wire Color Symbols in Section 0A (Page 0A-5)”.
Ignition System Components Location
B823H11802002
Refer to “Electrical Components Location in Section 0A (Page 0A-7)”.
#1
#2
#3
#4
CKP
sensor
TP
sensor
ECT
sensor
GP
switch
Engine stop switch
Side-stand
relay
Fuse
Fuse
Ignition
switch
Battery
ECM
I823H1180025-01
