Service Data: 0C-9
Tightening Torque List
B823H10307002
Engine
Item Nm kgf-m lb-ft
Exhaust pipe bolt 23 2.3 16.5
Exhaust pipe mounting bolt 23 2.3 16.5
Muffler mounting bolt (Front) 23 2.3 16.5
Muffler mounting bolt (Rear) 25 2.5 18.0
Muffler joint mounting bolt 23 2.3 16.5
Muffler connecting bolt 23 2.3 16.5
Speed sensor rotor bolt 28 2.8 20.0
Engine sprocket nut 145 14.5 105.0
Speed sensor bolt 6.5 0.65 4.7
Engine mounting bolt 55 5.5 40.0
Engine mounting nut 75 7.5 54.0
Engine mounting thrust adjuster 10 1.0 7.0
Engine mounting thrust adjuster lock-nut 45 4.5 32.5
Engine mounting pinch bolt 35 3.5 25.5
Cylinder head cover bolt 14 1.4 10.0
Spark plug 11 1.1 8.0
Cam chain guide No. 2 bolt 10 1.0 7.0
Camshaft journal holder bolt 10 1.0 7.0
Cam chain tension adjuster mounting bolt 10 1.0 7.0
Cylinder head side bolt 14 1.4 10.0
Cam chain tensioner bolt 23 2.3 16.5
Cylinder head bolt
[M6] 10 1.0 7.0
[M10]
Initial 25 2.5 18.0
Final 52 5.2 37.5
Cylinder nut [M6] 10 1.0 7.0
Water inlet connector bolt 10 1.0 7.0
Oil hose union bolt 18 1.8 13.0
Clutch cover bolt 10 1.0 7.0
Clutch sleeve hub nut 150 15.0 108.5
Clutch spring set bolt 10 1.0 7.0
Clutch spring support bolt 23 2.3 16.5
Starter clutch cover bolt 10 1.0 7.0
Starter torque limiter cover bolt 10 1.0 7.0
Starter clutch cover cap 11 1.1 8.0
Valve timing inspection cap 23 2.3 16.5
Starter clutch bolt 55 5.5 40.0
Generator cover bolt 10 1.0 7.0
Generator rotor bolt 120 12.0 87.0
Generator stator set bolt 11 1.1 8.0
Gearshift cover bolt 10 1.0 7.0
Gearshift cam stopper bolt 10 1.0 7.0
Gearshift cam stopper plate bolt 13 1.3 9.5
Gearshift arm stopper bolt 19 1.9 13.5
Oil pressure switch 14 1.4 10.0
Crankcase bolt
[M6] 11 1.1 8.0
[M8] 26 2.6 19.0
[M10] 50 5.0 36.0
Oil gallery plug
[M6] and [M8] 10 1.0 7.0
[M10] 18 1.8 13.0
[M14] 23 2.3 16.5
[M16] 35 3.5 25.5
Oil drain plug 23 2.3 16.5
Piston cooling oil jet bolt 10 1.0 7.0
Oil jet (For generator) 5 0.5 3.5
Oil pump mounting bolt 10 1.0 7.0
