Exterior Parts: 9D-6
Under Cowling Heat Shield Attachment
B823H19406017
Frame Cover Cushion Attachment
B823H19406018
1
“A”
I823H1940083-01
1. Heat shield
: Clean the adhesive surface before adhering the heat shield.
“A”: Align the tips of the heat shield to the alignment points on the under cowling.
1
“a”
“b”
1
“b”
I823H1940084-01
1. Cushion rubber
: Clean the adhesive surface before adhering the cushion rubber.
“a”: 50 mm (2.0 in) “b”: 20 mm (0.8 in)
