Clutch: 5C-23
Specifications
Service Data
B823H15307001
Clutch
Unit: mm (in)
Tightening Torque Specifications
B823H15307002
NOTE
The specified tightening torque is also described in the following.
“Clutch Hose Routing Diagram (Except for E-33) (Page 5C-2)”
“Clutch Hose Routing Diagram (For E-33) (Page 5C-3)”
“Clutch Control System Components (Page 5C-7)”
“Clutch Components (Page 5C-14)”
Reference:
For the tightening torque of fastener not specified in this section, refer to “Tightening Torque List in Section 0C
(Page 0C-9)”.
Item Standard Limit
Clutch drive plate thickness
No. 1 2.92 – 3.08 (0.115 – 0.121) 2.62 (0.103)
No. 2 & 3 3.72 – 3.88 (0.146 – 0.153) 3.42 (0.135)
Clutch drive plate claw width
No. 1 13.85 – 13.96 (0.542 – 0.550) 13.05 (0.514)
No. 2 & 3 13.90 – 14.00 (0.547 – 0.551) 13.10 (0.516)
Clutch driven plate distortion — 0.10 (0.004)
Clutch spring free length 37.13 (1.462) 35.3 (1.39)
Clutch master cylinder bore 14.000 – 14.043 (0.5512 – 0.5529) —
Clutch master cylinder piston diam. 13.957 – 13.984 (0.5495 – 0.5506) —
Clutch release cylinder bore 33.600 – 33.662 (1.3228 – 1.3253) —
Clutch release cylinder piston diam. 33.550 – 33.575 (1.3209 – 1.3218) —
Clutch fluid type Brake fluid DOT 4 —
Fastening part
Tightening torque
Note
Nmkgf-mlb-ft
Air bleeder valve (Clutch)
60.6 4.5
)(Page 5C-5) /
)(Page 5C-6)
Clutch master cylinder holder bolt 10 1.0 7.0 )(Page 5C-8)
Clutch hose union bolt
23 2.3 16.5
)(Page 5C-9) /
)(Page 5C-12)
Clutch lever pivot bolt 1.0 0.1 0.7 )(Page 5C-10)
Clutch lever pivot bolt lock-nut 6.0 0.6 4.5 )(Page 5C-10)
Clutch release mounting bolt 10 1.0 7.0 )(Page 5C-12)
Clutch spring support bolt 23 2.3 16.5 )(Page 5C-18)
Clutch sleeve hub nut 150 15.0 108.5 )(Page 5C-19)
Clutch spring set bolt 10 1.0 7.0 )(Page 5C-20)
Clutch cover bolt 10 1.0 7.0 )(Page 5C-21)
