Combination Meter / Fuel Meter / Horn: 9C-11
Specifications
Service Data
B823H19307001
Wattage
Unit: W
Tightening Torque Specifications
B823H19307002
Reference:
For the tightening torque of fastener not specified in this section, refer to “Tightening Torque List in Section 0C
(Page 0C-9)”.
Special Tools and Equipment
Special Tool
B823H19308001
Item
Specification
E-02, 19, 24 The other countries
Headlight
HI 60 m
LO 55 m
Parking or position light 5 x 2 m
Brake light/Taillight LED m
Turn signal light 21 x 4 m
License plate light 5 m
Tachometer light LED m
Speedometer light LED m
Turn signal indicator light LED m
High beam indicator light LED m
Neutral position indicator light LED m
Oil pressure indicator light LED m
FI indicator light LED m
Engine coolant temp. indicator light LED m
Immobilizer indicator light LED —
Fastening part
Tightening torque
Note
Nmkgf-mlb-ft
Speed sensor mounting bolt 6.5 0.65 4.7 )(Page 9C-7)
09900–25008
Multi-circuit tester set
)(Page 9C-6) / )(Page 9C-
7) / )(Page 9C-8) /
)(Page 9C-9) / )(Page 9C-
9)
