Engine Mechanical: 1D-102
NOTE
The specified tightening torque is also described in the following.
“Throttle Body Components (Page 1D-8)”
“Throttle Body Construction (Page 1D-9)”
“Engine Assembly Installation (Page 1D-25)”
“Engine Bottom Side Assembly (Page 1D-72)”
Reference:
For the tightening torque of fastener not specified in this section, refer to “Tightening Torque List in Section 0C
(Page 0C-9)”.
Special Tools and Equipment
Recommended Service Material
B823H11408001
PCV cover bolt 10 1.0 7.0 )(Page 1D-88)
PCV reed valve cover bolt 10 1.0 7.0 )(Page 1D-88)
Conrod cap bolt 21 Nm (2.1 kgf-m, 15.0 Ib-ft) then turn in 1/
4 (90q) turn
)(Page 1D-91) /
)(Page 1D-93)
Crankcase journal bolt (Initial) 18 1.8 13.0 )(Page 1D-95)
Crankcase journal bolt (Final) 32 3.2 23.0 )(Page 1D-95)
Fastening part
Tightening torque
Note
Nmkgf-mlb-ft
Material SUZUKI recommended product or Specification Note
Grease SUZUKI SUPER GREASE A or
equivalent
P/No.: 99000–25010 )(Page 1D-14) /
)(Page 1D-14) /
)(Page 1D-80) /
)(Page 1D-81) /
)(Page 1D-82) /
)(Page 1D-84) /
)(Page 1D-84) /
)(Page 1D-86)
Molybdenum oil MOLYBDENUM OIL SOLUTION — )(Page 1D-32) /
)(Page 1D-36) /
)(Page 1D-52) /
)(Page 1D-78) /
)(Page 1D-89) /
)(Page 1D-90) /
)(Page 1D-91)
Sealant SUZUKI BOND No.1207B or
equivalent
P/No.: 99000–31140 )(Page 1D-42) /
)(Page 1D-50) /
)(Page 1D-75) /
)(Page 1D-81) /
)(Page 1D-86) /
)(Page 1D-88)
Thread lock cement THREAD LOCK CEMENT SUPER
1303 or equivalent
P/No.: 99000–32030 )(Page 1D-83)
THREAD LOCK CEMENT SUPER
1322 or equivalent
P/No.: 99000–32110 )(Page 1D-74) /
)(Page 1D-79) /
)(Page 1D-80) /
)(Page 1D-80) /
)(Page 1D-80) /
)(Page 1D-82) /
)(Page 1D-83)
