0A-9 General Information:
Specifications
Specifications
B823H10107001
NOTE
These specifications are subject to change without notice.
Dimensions and dry mass
Engine
Drive train
Item Specification Remark
Overall length
2 245 mm (88.4 in) E-03, 28, 33
2 220 mm (87.4 in) Others
Overall width 800 mm (31.5 in)
Overall height 1 085 mm (42.7 in)
Wheelbase 1 525 mm (60.0 in)
Ground clearance 120 mm (4.7 in)
Seat height 805 mm (31.7 in)
Dry mass
236 kg (520 lbs) E-33
235 kg (518 lbs) Others
Item Specification Remark
Type 4-stroke, Liquid-cooled, DOHC
Number of cylinders 4
Bore 81.0 mm (3.189 in)
Stroke 65.0 mm (2.559 in)
Displacement 1 340 cm
3
(81.8 cu. in)
Compression ratio 12.5 : 1
Fuel system Fuel injection system
Air cleaner Paper element
Starter system Electric
Lubrication system Wet sump
Idle speed 1 150 r 100 r/min
Item Specification Remark
Clutch Wet multi-plate type
Transmission 6-speed constant mesh
Gearshift pattern 1-down, 5-up
Primary reduction ratio 1.596 (83/52)
Gear ratios
Low 2.615 (34/13)
2nd 1.937 (31/16)
3rd 1.526 (29/19)
4th 1.285 (27/21)
5th 1.136 (25/22)
Top 1.043 (24/23)
Final reduction ratio 2.388 (43/18)
Drive chain RK GB50GSV Z4, 118 links
