Manual Transmission: 5B-19
Specifications
Service Data
B823H15207001
Drive Train
Unit: mm (in) Except ratio
Tightening Torque Specifications
B823H15207002
NOTE
The specified tightening torque is also described in the following.
“Transmission Components (Page 5B-2)”
“Gearshift Lever Construction (Page 5B-13)”
“Gearshift Shaft / Gearshift Cam Plate Components (Page 5B-14)”
“Gearshift Shaft Construction (Page 5B-15)”
Reference:
For the tightening torque of fastener not specified in this section, refer to “Tightening Torque List in Section 0C
(Page 0C-9)”.
Item Standard Limit
Primary reduction ratio 1.596 (83/52) —
Final reduction ratio 2.388 (43/18) —
Gear ratios
Low 2.615 (34/13) —
2nd 1.937 (31/16) —
3rd 1.526 (29/19) —
4th 1.285 (27/21) —
5th 1.136 (25/22) —
Top 1.043 (24/23) —
Shift fork to groove clearance 0.1 – 0.3 (0.004 – 0.012) 0.5 (0.02)
Shift fork groove width 5.0 – 5.1 (0.197 – 0.201) —
Shift fork thickness 4.8 – 4.9 (0.189 – 0.193) —
Drive chain
Type RK GB50GSVZ4 —
Links 118 links —
20-pitch
length
— 319.4 (12.57)
Drive chain slack (on side-stand) 20 – 30 (0.79 – 1.18) —
Gearshift lever height 55 – 65 (2.2 – 2.6) —
Fastening part
Tightening torque
Note
Nmkgf-mlb-ft
Bearing retainer screw 8 0.8 6.0 )(Page 5B-5)
Gear position switch mounting bolt 6.5 0.65 4.7 )(Page 5B-12)
Gear position switch lead wire clamp bolt 6.5 0.65 4.7 )(Page 5B-12)
To Next Page
