9B-17 Lighting Systems:
Specifications
Service Data
B823H19207001
Wattage
Unit: W
Tightening Torque Specifications
B823H19207002
NOTE
The specified tightening torque is also described in the following.
“Rear Lighting System Construction (Page 9B-9)”
“License Plate Light Components (Page 9B-11)”
“Rear Turn Signal Light Components (Page 9B-13)”
“Reflex Refractor Construction (Page 9B-14)”
Reference:
For the tightening torque of fastener not specified in this section, refer to “Tightening Torque List in Section 0C
(Page 0C-9)”.
Special Tools and Equipment
Recommended Service Material
B823H19208001
Special Tool
B823H19208002
Item
Specification
E-02, 19, 24 The other countries
Headlight
HI 60 m
LO 55 m
Parking or position light 5 x 2 m
Brake light/Taillight LED m
Turn signal light 21 x 4 m
License plate light 5 m
Fastening part
Tightening torque
Note
Nmkgf-mlb-ft
Rear turn signal light mounting nut
70.7 5.0
)(Page 9B-11) /
)(Page 9B-13)
Rear fender mounting bolt 10 1.0 7.0 )(Page 9B-11)
Rear license plate light mounting nut 5 0.5 3.5 )(Page 9B-12)
Material SUZUKI recommended product or Specification Note
Thread lock cement THREAD LOCK CEMENT SUPER
1322 or equivalent
P/No.: 99000–32110 )(Page 9B-11)
09900–25008
Multi-circuit tester set
)(Page 9B-15) /
)(Page 9B-16) /
)(Page 9B-16) /
)(Page 9B-16)
To Next Page
