4B-9 Front Brakes:
Specifications
Service Data
B823H14207001
Brake
Unit: mm (in)
Tightening Torque Specifications
B823H14207002
NOTE
The specified tightening torque is also described in the following.
“Front Brake Components (Page 4B-1)”
Reference:
For the tightening torque of fastener not specified in this section, refer to “Tightening Torque List in Section 0C
(Page 0C-9)”.
Item Standard Limit
Brake disc thickness Front 5.3 – 5.7 (0.21 – 0.22) 5.0 (0.20)
Brake disc runout — 0.30 (0.012)
Brake caliper cylinder bore Front
Leading 30.230 – 30.280 (1.1902 – 1.1921) —
Trailing 33.960 – 34.010 (1.3370 – 1.3390) —
Brake caliper piston diam. Front
Leading 30.148 – 30.198 (1.1869 – 1.1889) —
Trailing 33.878 – 33.928 (1.3338 – 1.3357) —
Brake fluid type DOT 4 —
Fastening part
Tightening torque
Note
Nmkgf-mlb-ft
Front brake pad mounting pin 17 1.7 12.5 )(Page 4B-3)
Pad pin plug 2.5 0.25 1.8 )(Page 4B-3)
Front brake caliper mounting bolt 39 3.9 28.0 )(Page 4B-4)
Front brake caliper housing bolt
27 2.7 19.5
)(Page 4B-4) /
)(Page 4B-6)
Brake hose union bolt 23 2.3 16.5 )(Page 4B-4)
Brake disc bolt (Front) 23 2.3 16.5 )(Page 4B-7)
To Next Page
