Air Bag System: 8B-11
DTC Table
S7RS0B8204003
SDM DTC
4 1) Check DTC using SUZUKI scan tool referring to “DTC
Check”.
Is “NO CODES” displayed on SUZUKI scan tool?
Air bag system is in
good condition.
An intermittent trouble
has occurred at some
place.
Check the connector
harness, etc. related to
the sensed DTC.
Refer to “Inspection of
Intermittent and Poor
Connections”.
Then clear DTC
(referring to “DTC
Clearance”.) and repeat
this flow.
5 Check DTC using SUZUKI scan tool, referring to “DTC
Check”.
Is “NO CODES” displayed on SUZUKI scan tool?
Substitute a known-
good SDM and recheck.
Check and repair
according to flow
corresponding to that
DTC.
Step Action Yes No
DTC Diagnosis
—Normal —
) B1013
SDM
SDM fault Diagnose
trouble
according to
diagnostic flow
corresponding
to each code
No.
) B1014
“AIR BAG”
warning right
circuit failure
) B1016
Power
source
voltage
Too high
) B1017 Too low
) B1021
SDM
Front air bag
module
exploded
) B1024
Driver side-air
bag module
exploded
) B1025
Passenger
side-air bag
module
exploded
) B1026
Pretensioner
activated
) B1027
Reusable
number
exceeded
) B1031
Driver air
bag circuit
Resistance
high
) B1032 Resistance low
) B1033 Short to ground
) B1034
Short to power
circuit
) B1041
Passenger
air bag
circuit
Resistance
high
) B1042 Resistance low
) B1043 Short to ground
) B1044
Short to power
circuit
) B1051
Driver
pretensioner
circuit
Resistance
high
) B1052 Resistance low
) B1053 Short to ground
) B1054
Short to power
circuit
) B1055
Passenger
pretensioner
circuit
Resistance
high
) B1056 Resistance low
) B1057 Short to ground
) B1058
Short to power
circuit
) B1061
Driver side-
air bag
Resistance
high
) B1062 Resistance low
) B1063 Short to ground
) B1064
Short to power
circuit
) B1065
Passenger
side-air bag
Resistance
high
) B1066 Resistance low
) B1067 Short to ground
) B1068
Short to power
circuit
) B1071
Forward-
sensor
circuit
Performance
problem
) B1072
Communicatio
n error
) B1073 Short to ground
) B1074
Short to power
circuit or open
DTC Diagnosis
