1A-18 Engine General Information and Diagnosis:
Engine and Emission Control Input / Output Table
S7RS0B1101012
INPUT
OUTPUT
ELECTRIC CONTROL DEVICE
BAROMETRIC PRESSURE SENSOR
STOP LAMP SWITCH
START SWITCH
IGNITION SWITCH
A/C REFRIGERANT PRESSURE SENSOR
BLOWER SWITCH
A/C SWITCH
A/C EVAP OUTLET AIR TEMP. SENSOR (Manual A/C model)
ABS/ESP
® CONTROL MODULE (Wheel Speed Signal)
HO2S-1
HO2S-2
IAT SENSOR
MAF SENSOR
ECT SENSOR
TP SENSOR
MAP SENSOR
CMP SENSOR
CKP SENSOR
KNOCK SENSOR
ABS/ESP
® CONTROL MODULE (ABS active signal / ESP® status signal)
IMMOBILIZER CONTROL MODULE (in ECM)
APP SENSOR
FUEL PUMP RELAY FUEL INJECTOR HO2S HEATER
THROTTLE ACTUATOR THROTTLE ACTUATOR CONTROL RELAY
IGNITION COIL WITH IGNITER EGR VALVE EVAP CANISTER PURGE VALVE A/C COMPRESSOR RELAY RADIATOR FAN RELAY MIL MAIN RELAY OIL CONTROL VALVE
(VVT model)
SIGNAL FROM SENSOR, SWITCH AND CONTROL MODULE
I7RS0B110009-03
