4F-24 Electronic Stability Program:
Circuit Description
Operation (ON/OFF) of ABS warning lamp is controlled by ESP® control module through lamp driver module in
combination meter.
If antilock brake system is in good condition, ESP® control module turns ABS warning lamp ON at the ignition switch
ON, keeps it ON for 2 seconds and then turns it OFF. If an abnormality in the system is detected, ABS warning lamp is
turned ON continuously by ESP® control module. Also, it is turned ON continuously by lamp driver module when the
connector of ESP® control module is disconnected.
Troubleshooting
Refer to “Troubleshooting” under “ESP® Warning Lamp Does Not Come ON at Ignition Switch ON”.
ABS Warning Lamp Comes ON Steady
S7RS0B4604049
Wiring Diagram
Refer to “Wiring Diagram” under “ABS Warning Lamp Does Not Come ON at Ignition Switch ON”.
Circuit Description
Refer to “Circuit Description” under “ABS Warning Lamp Does Not Come ON at Ignition Switch ON”.
Troubleshooting
Refer to “Troubleshooting” under “ESP® Warning Lamp Comes ON Steady”.
EBD Warning Lamp (Brake Warning Lamp) Comes ON Steady
S7RS0B4604050
Wiring Diagram
[A]
E85
16
1
15
2
3
4
5
6
7
8
9
10
11
12
13
14
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
WHT
GRN
3
E85-13
E85-44
RED
WHT
8
5
E46-1
E46-2
4
13
8
E85-16
E85-47
BLK
BLK
11
10
12
BLK/ORN
RED
WHT
RED
WHT
G37-4
G37-2
G28-10
G28-8
G28-16
12V
12V
E85-32
E85-1
E85-35
WHT/RED
WHT/BLU
GRN/ORN
8
2
1
9
14
15
[B]
G37E46
1245367
891011121314
1245367
891011
1213141516171819202122
[C]
G28
12345678910111213141516
17181920212223242526272829303132
12V
12V
6
7
E46-5
L01-6
RED/BLK
RED/BLK
G28-31
RED/BLK
I6RS0B460011-01
[A]: ESP® control module connector (viewed from terminal side) 4. Junction block assembly 10. EBD warning lamp (brake warning lamp)
[B]: BCM connector (viewed from harness side) 5. BCM (included in junction block
assembly)
11. ABS warning lamp
[C]: Combination meter connector (viewed from harness side) 6. Brake fluid level switch 12. Lamp driver module
1. Battery 7. Parking brake switch 13. ESP® hydraulic unit / control module
assembly
2. Main fuse box 8. CAN driver 14. Junction connector
3. Ignition switch 9. Combination meter 15. To steering angle sensor
