Automatic Transmission/Transaxle: 5A-19
DTC Table
S7RS0B5104005
NOTE
• A: Driving cycles when transmission warning light lighting and storing DTC in TCM memory.
• *1: Transmission warning light does not light up but TCM detects and stores DTC.
• For details of driving cycle, refer to “On-Board Diagnostic System Description”.
DTC No. Detecting item
Detecting condition
(DTC will set when detecting)
A
) P0602 Control module programming error Data programming error. *1, 1 driving cycle
) P0705
Transmission range sensor circuit
malfunction (PRNDL input)
Multiple signals are inputted simultaneously. 1 driving cycle
) P0707
Transmission range sensor circuit
low
No sensor signal is inputted. 2 driving cycles
) P0712
Transmission fluid temperature
sensor “A” circuit low
Sensor output voltage is too low. 1 driving cycle
) P0713
Transmission fluid temperature
sensor “A” circuit high
Sensor output voltage is too high. 1 driving cycle
) P0717
Input / Turbine speed sensor circuit
no signal
No sensor signal is detected although output
speed sensor signal is inputted.
1 driving cycle
) P0722 Output speed sensor circuit no signal
No sensor signal is inputted although input
speed sensor signal is inputted.
1 driving cycle
) P0787 Shift / Timing solenoid low
Voltage of timing solenoid terminal is low
although TCM is commanding timing solenoid
to turn ON.
1 driving cycle
) P0788 Shift / Timing solenoid high
Voltage of timing solenoid terminal is high
although TCM is commanding timing solenoid
to turn OFF.
1 driving cycle
) P0961
Pressure control solenoid “A” control
circuit range / performance
Difference between target current of control
solenoid valve circuit and monitor current of
control solenoid valve circuit is more than
specification.
1 driving cycle
) P0962
Pressure control solenoid “A” control
circuit low
No electric flow is detected on pressure control
solenoid circuit.
1 driving cycle
) P0963
Pressure control solenoid “A” control
circuit high
Too much electric flow is detected on pressure
control solenoid circuit.
1 driving cycle
) P0973 Shift solenoid “A” control circuit low
Voltage of shift solenoid terminal is low
although TCM is commanding shift solenoid to
turn ON.
1 driving cycle
) P0974 Shift solenoid “A” control circuit high
Voltage of shift solenoid terminal is high
although TCM is commanding shift solenoid to
turn OFF.
1 driving cycle
) P0976 Shift solenoid “B” control circuit low
Voltage of shift solenoid terminal is low
although TCM is commanding shift solenoid to
turn ON.
1 driving cycle
) P0977 Shift solenoid “B” control circuit high
Voltage of shift solenoid terminal is high
although TCM is commanding shift solenoid to
turn OFF.
1 driving cycle
) P1702
Internal control module memory
check sum error
Calculation of current data stored in TCM is not
correct comparing with pre-stored checking
data in TCM.
1 driving cycle
) P1703 CAN invalid data - TCM
TCM receives malfunction signal of throttle
position
, engine coolant temperature, engine
revolution and engine torque from ECM.
*1, 1 driving cycle
) P1723 Range select switch malfunction
“3” position switch ON signal is inputted
although transmission range switch signal is
inputted P, R, N or L. range.
*1, 1 driving cycle
) P1774
Control module communication bus
off
Transmitting and receiving error detected to
TCM for specified time continuously.
1 driving cycle
