4E-35 ABS:
Specifications
Tightening Torque Specifications
S7RS0B4507001
NOTE
The specified tightening torque is also described in the following.
“Front Wheel Speed Sensor Components Location”
“Rear Wheel Speed Sensor Components Location”
“ABS Hydraulic Unit / Control Module Assembly Components”
Reference:
For the tightening torque of fastener not specified in this section, refer to “Fasteners Information in Section 0A”.
Special Tools and Equipment
Special Tool
S7RS0B4508001
Fastening part
Tightening torque
Note
N⋅mkgf-mlb-ft
Brake pipe flare nut 16 1.6 11.5 )
ABS hydraulic unit / control module assembly
bolt
90.9 6.5
)
ABS hydraulic unit / control module assembly
bracket bolt
25 2.5 18.0
)
Front wheel speed sensor bolt 25 2.5 18.0 )
Front wheel speed sensor harness clamp bolt 11 1.1 8.0 )
Rear wheel speed sensor bolt 11 1.1 8.0 )
Rear wheel speed sensor harness clamp bolt 11 1.1 8.0 )
09950–78220 SUZUKI scan tool
Flare nut wrench (10 mm) —
) This kit includes following
items. 1. Tech 2, 2. PCMCIA
card, 3. DLC cable, 4. SAE
16/19 adapter, 5. Cigarette
cable, 6. DLC loop back
adapter, 7. Battery power
cable, 8. RS232 cable, 9.
RS232 adapter, 10. RS232
loop back connector, 11.
Storage case, 12. ) / )
