6C-48 Power Assisted Steering System:
Specifications
Tightening Torque Specifications
S7RS0B6307001
NOTE
The specified tightening torque is also described in the following.
“Steering Gear Case Assembly Components”
Reference:
For the tightening torque of fastener not specified in this section, refer to “Fasteners Information in Section 0A”.
Fastening part
Tightening torque
Note
N⋅mkgf-mlb-ft
Tie-rod end nut 45 4.5 32.5 )
Tie-rod end lock nut 45 4.5 32.5 ) / )
Wheel nut 85 8.5 61.5 )
Steering gear case mounting No.1 bolt 55 5.5 40.0 )
Steering gear case mounting No.2 bolt 55 5.5 40.0 )
Steering gear case mounting No.3 bolt 40 4.0 29.0 )
Earth cable bolt 4.5 0.45 3.5 )
Tie-rod 93 9.3 67.5 )
Rack damper screw Tighten 25 N⋅m (2.5 kgf-m, 18.0 lb-ft) and
loosen 180° and then tighten 3.9 N⋅m (0.39
kgf-m, 3.0 lb-ft) and turn it back by 7 ± 3° by
the specified procedure.
)
Rotation torquer of pinion 2.0 0.2 1.5 )
Rack damper screw lock nut 64 6.4 46.5 )
P/S control module bracket screw (ABS model) 9 0.9 6.5 )
P/S control module bracket screw (ESP®
model)
70.7 5.0
)
P/S control module mounting screw 5 0.5 3.7 )
