Hood / Fenders / Doors: 9J-6
Rear End Door Assembly Components
S7RS0B9A06009
Rear End Door Assembly Removal and
Installation
S7RS0B9A06010
WARNING
!
Be careful enough when you open and shut
with door balancer has not adhered to Rear
end door.
Otherwise, Rear end door doses in weight
and is injured.
Removal
1) Remove rear end door trim (1).
2) Remove related section of head lining and rear trim.
3) Disconnect rear end door harness couplers (2) and
washer hose (3).
4) Remove rear end door balancers (4).
5) Remove door hinge nuts (5) and remove rear end
door assembly (6).
3
(a)
(a)
1
2
6
5
[A]
1
7
9
8
(b)
4
I6RS0B9A0001-01
[A]: Rear end door spoiler installation position 4. Rear end door balancer
: Never disassemble rear end door
balancer.
8. Cap
1. Rear end door panel assembly 5. Rear end door trim 9. Rubber nut
2. Rear end door window glass 6. Rear end door opening wether-strip : 23 N⋅m (2.3 kgf-m, 17.0 lb-ft)
3. Rear end door hinge
: Apply lithium grease 99000-25010 to door hinge
moving section.
: Apply sealant 99000-31110 to contact face.
7. Rear end door spoiler : 5 N⋅m (0.5 kgf-m, 4.0 lb-ft)
“A”
“B”
“B”
“A”
“B”
“A”
“A”
“A”
“A” “A”
“A”
“A”
1
6
5
4
2
3
2
4
I4RS0A9A0011-01
