Suzuki Swift Sport 2004 User Manual

Power Assisted Steering System: 6C-13
Serial Data Link Circuit Check
S7RS0B6304009
CAUTION
!
Be sure to perform “EPS System Check” before starting “Troubleshooting”.
Wiring Diagram
Vehicle pulls to one side
during straight driving
Poor performance of torque sensor Check torque sensor referring to “Torque
Sensor and Its Circuit Inspection”.
Steering gear case assembly faulty Replace.
Poor recovery after turns Poor performance of torque sensor Check torque sensor referring to “Torque
Sensor and Its Circuit Inspection”.
Steering column faulty Replace.
Abnormal noise P/S motor (built in steering gear case
assembly) malfunction
Replace steering gear case assembly.
No idle up P/S control module faulty Check P/S control module referring to
“Inspection of P/S Control Module and Its
Circuits”.
Condition Possible cause Correction / Reference Item
M
BLK
RED
E52-11
E51-1
E51-2
PPL/WHT
[A]
12
3
4
5
67
8
9
11
10
12 13
14
15
16
17 18 19
20
10 9 8 7 654321
16 15 14 13 12 11
26 25 24 23 22 21 20 19 18 17
32 31 30 29 28 27
[C]
8
7
9
12V
[B]
11
1
2
GRY
LT GRN
/BLK
E52-1
E52-5
E49-1
GRN
GRN
WHT
BLK
WHY
G28-25G28-31
RED/BLK
10
3
4
4
5
6
4
4
1
2
4
E49-2
BLK
I7RS0B630003-01
[A]: Connector “E52” (viewed from harness side) 3. Junction block assembly 8. P/S control module
[B]: Connector “E49” (viewed from harness side) 4. Fuse 9. To ECM, BCM, Air bag SDM control module and ABS control
module assembly
[C]: Connector “G28” (viewed from harness side) 5. Combination meter 10. Individual circuit fuse box No.1
1. Main fuse box 6. “EPS” warning light 11. Serial data circuit
2. Ignition switch 7. Date link connector (DLC)
