Automatic Transmission/Transaxle: 5A-33
Troubleshooting
“P” Range Test
S7RS0B5104017
1) Stop vehicle on a slope of 5 degrees or more, shift select lever to “P” range and at the same time apply parking
brake.
2) After stopping engine, depress brake pedal and release parking brake.
3) Then, release brake pedal gradually and check that vehicle remains stationary.
4) Depress brake pedal and shift select lever to “N” range.
5) Then, release brake pedal gradually and check that vehicle moves.
WARNING
!
Before test, make sure no one is around vehicle or down on a slope and keep watchful for safety
during test.
Troubleshooting
Condition Possible cause Correction / Reference Item
Higher than standard
level in each range
Malfunction of pressure control solenoid
valve (Low line pressure)
Inspect. If NG, replace valve body assembly.
Faulty valve body component Replace valve body assembly.
Lower than standard level
in each range
Malfunction of pressure control solenoid
valve (Low line pressure)
Inspect. If NG, replace valve body assembly.
Faulty valve body component Replace valve body assembly.
Clogged oil strainer Replace.
Faulty oil pump Inspect. If NG, replace.
Leakage from both “D” and “R” range
fluid pressure circuit
Replace valve body assembly.
Lower than standard level
only in “D” range
Leakage from “D” range fluid pressure
circuit
Replace valve body assembly.
Lower than standard level
only in “R” range
Leakage from “R” range fluid pressure
circuit
Replace valve body assembly.
Condition Possible cause Correction / Reference Item
Vehicle moves at “P”
range or remains
stationary at “N” range
Defective parking lock pawl or spring Inspect. If NG, repair.
