9A-73 Wiring Systems:
C-1 Combination Meter Circuit Diagram (Meter)
S7RS0B910E019
RADIO
J/B
15A
40
METER
10A
25
WHT/RED
G28
32
31
5
Stepper motor and LED
output driver
Voltage regulator
Micro controller
ILL
(Dial)
ILL
(Display)
ILL
(Pointer)
G33
6
RED/BLK
16
B
B
BLK /ORN
BLK /ORN
J/C
(CAN)
G15
FUELTEMPTAC HOSPEED
10
CAN
High Low
WHT
RED
LCD
"A-8"
RW
10
8
BCM
I6RS0C910920-01
