4F-18 Electronic Stability Program:
NOTE
•“{” in ABS warning lamp, EBD warning lamp and ESP® warning lamp column of the above table
means warning lamp is lit when DTC is detected.
• *1: If two or more wheel speed sensor are defective, ABS warning lamp, EBD warning lamp and
ESP® warning lamp are lit and all the control functions are deactivated. If one wheel speed sensor is
defective, ABS warning lamp and ESP® warning lamp are lit and ABS and TCS / stability control are
deactivated.
• *2: SLIP indicator lamp and ESP® OFF lamp turn ON when power supply circuit voltage is low.
• *3: SLIP indicator lamp flashes continuously at Intervals of 1 Hz.
• *4: EBD warning lamp is lit when power supply circuit voltage is too low.
DTC Clearance
S7RS0B4604006
WARNING
!
When performing a driving test, select a safe place where there is neither any traffic nor any traffic
accident possibility and be very careful during testing to avoid occurrence of an accident.
1) Connect SUZUKI scan tool to data link connector in the same manner as when making this connection for DTC
check.
2) Turn ignition switch to ON position.
3) Erase DTC according to instructions displayed on scan tool. Refer to scan tool operator’s manual for further
derails.
4) After completing the clearance, turn ignition switch OFF and disconnect scan tool from data link connector.
5) Perform “Driving Test” (Step 2 of “Electronic Stability Program System Check”) and “DTC Check” and confirm that
NO DTC is displayed on scan tool.
) U1100
Lost communication with
ECM (reception error)
ECM message data is missing from
CAN communication.
——{
) U1126
Lost communication with
steering angle sensor
(reception error)
Steering angle sensor message
data is missing from CAN
communication.
——{
) U1140
Lost communication with
BCM (reception error)
BCM message data is missing from
CAN communication.
——{
DTC (displayed
on SUZUKI scan
tool)
Diagnostic Items
Detecting condition (DTC will
beset when detecting)
ABS
warning
lamp
EBD
warning
lamp
ESP®
warning
lamp
