Body Electrical Control System: 10B-2
CAN Communication System Description
S7RS0BA201002
Refer to “CAN Communication System Description in Section 1A” for CAN communication system description. BCM
communication control data with each control module as follows.
BCM Transmission Data
BCM Reception Data
A/C switch ON signal
Electric load signal
"3" position switch signal
Illumination ON signal
Brake fluid level switch signal
Parking brake switch signal
Seat belt buckle switch signal
Charging system signal
Engine oil pressure switch signal
Diagnostic trouble code (DTC)
Door switch status
Door lock status
ECM
TCM
(A/T model)
Combination
Meter
Keyless Start
Control Module
(if equipped)
Transmit
DATABCM
ESP
Control
Module
(if equipped)
I7RS0BA20002-01
Engine speed signal
Vehicle speed signal
Engine coolant temperature signal
A/C refrigerant pressure signal
Fuel consumption signal
A/C compressor clutch signal
Transmission range sensor signal
Fuel level signal
Ignition knob switch signal
Door lock/unlock request signal
Buzzer request signal
Answer back request signal
DATABCM
Receive
Combination
Meter
TCM
(A/T model)
Keyless Start
Control Module
(if equipped)
ECM
I7RS0AA20001-01
