Heater and Ventilation: 7A-1
HVAC
Heater and Ventilation
General Description
Heater and Ventilation Construction
S7RS0B7101001
NOTE
The figure shows left-hand steering vehicle. For right-hand steering vehicle, parts with (*) are installed
at the opposite side.
I4RS0B710001-01
1. HVAC unit 5. Side ventilation air 9. Fresh air 13. Blower motor
