Body Electrical Control System: 10B-12
Scan Tool Data
S7RS0BA204003
Scan tool Data Condition
Normal condition /
reference value
Vehicle Speed At stop with ignition switch turned ON 0 km/h
Outside air Temp Reference value is relative to outside air temperature
–40 °C – 70 °C
(–40 °F – 158 °F)
Battery Voltage At specified idle speed after warming up 10 – 14 V
Coolant Temp At specified idle speed after warming up
80 °C – 100 °C
(176 °F – 212 °F)
Engine Speed Engine idling with no load applied after warming up
Desired idle speed
± 50 rpm
Fuel Consumption At specified idle speed after warming up 0.0 km/l
Key Reminder Sw
Ignition key inserted in ignition key cylinder Key in
Ignition key pulled out from ignition key cylinder Pulled
Rear Wiper Sw
Rear wiper switch at ON position and ignition switch turned ON ON
Rear wiper switch at INT position and ignition switch turned ON INT
Rear wiper switch at OFF position and ignition switch turned ON OFF
Door key Sw
Key cylinder switch of driver side door at lock position LOCK
Key cylinder switch of driver side door not turned Neutral
Key cylinder switch of driver side door at unlock position Unlock
Door Lock Sw
Lock side of manual door lock switch pressed LOCK
Manual door lock switch not pressed Neutral
Unlock side of manual door lock switch pressed Unlock
Driv Door Sw
Driver side door open Open
Driver side door closed Close
Pass Door Sw
Doors other than driver side door open Open
Doors other than driver side door closed Close
Brake Fluid Level
Brake fluid level at MIN level or higher Normal
Brake fluid level lower than MIN level Low
Parking Brake Sw
Parking brake lever pulled ON
Parking brake lever released OFF
Rear Defogger Sw
Rear end door window defogger switch turned ON with engine
running
ON
Rear end door window defogger switch turned OFF with engine
running
OFF
Tail Light Sw
Lighting switch at HEAD or CLEARANCE position ON
Lighting switch at OFF position OFF
Driv Seatbelt Sw
Driver side seat belt fastened Fasten
Driver side seat belt unfastened Unfasten
Rear end door opener
Rear end door open ON
Rear end door closed OFF
“3” Position Sw
A/T select lever at 2nd or 3rd position with ignition switch turned
ON
ON
A/T select lever at other than 2nd or 3rd position with ignition
switch turned ON
OFF
Charge Lamp
Engine at stop with ignition switch turned ON ON
Engine running OFF
Oil pressure switch
Engine at stop with ignition switch turned ON ON
Engine running OFF
A/C Switch
A/C and ignition switch turned ON ON
A/C switch turned OFF OFF
To Next Page
