Commands listed in alphabetical order
HAVERSINe
CARDIac
ARBitrary
Examples
AFG:FUNC LOREN specifies to generate the Lorentz function.
AFG:FUNCTION? might return :AFG:FUNCTION SINE indicating the AFG
function is set to sine.
AFG:HIGHLevel
This command sets (or queries) the high level value of the output waveform, in
volts, when using the arbitrary function generator feature.
Conditions
Requires option AFG.
Group
AFG
Syntax
AFG:HIGH
Level <N R3>
AFG:HIGHLevel?
Arguments
Floating point number that represents the AFG high level value, in volts.
Exampl
es
AFG:HIGHLEVEL 1.0 sets the AFG high level value to 1.0 volts.
AFG:HIGHLEVEL? might return :AFG:HIGHLEVEL 1.5000 indicating the high
level is set to 1.5 Volts.
AFG:LOWLevel
This command sets (or queries) the low level value of the output waveform, in
volts, when using the arbitrary function generator feature.
Conditions
Requires option AFG.
Group
AFG
Syntax
AFG:LOWLevel <NR3>
AFG:LOWLevel?
2-102 MSO54, MSO56, MSO58, MSO58LP Programmer
