• During bypass feed, the trailing edge of the paper will come out from the back of the
machine, and then reverse feed back into the machine.
Controller Options
If you intend to install one or more of the following options which require the installation of boards, do
so before you re-attach the rear cover.
• File Format Converter (MLB)
• IEEE 802.11 a/g/n Interface Unit
Connecting the Scanner and Main Unit
Connect the scanner unit and main unit with the scanner cable and fix them with the joint brackets.
Parts to be Used
No. Item Q'ty
- Joint Bracket 2
- Harness Clamp 3
- Power Cord 1
- Tapping Screw M4x8 8
Main Machine Installation
103
To Next Page
