Carriage Unit
Before You Begin
• Set the main power switch to OFF and disconnect the power plug from the power outlet before
performing the procedure below. Working with power supplied may cause electrical shock or
defects.
• Always follow instructions and work carefully to avoid spilling ink from the ink tubes and the tops of
the ink sub tanks.
• If ink spills onto a printed circuit board at the base of the FFC, the print head unit will become
unusable and require replacement.
1. Horizontal line on both the left and right margins.
• The width of the left and right margins must be the same.
• The width of the left and right margins must be in the range: 2.5 to 3.0 mm.
2. If the left and right margins are the same size and within the range 2.5 to 3.0 mm, no adjustment is
necessary.
-or-
If the margins need adjustment, do the following steps.
4. Replacement and Adjustment
406
