• This SP code is used to modify the initial ink filling sequence at installation and after one or
more print heads have been replaced. Every time the machine is turned on, the machine
checks the ink level in each sub tank. If ink is low, then the machine switches on the ink pump
motor(s) to fill the tank(s).
• This SP should always be set to "0" unless there are specific instructions that it should be reset
temporarily.
14. Discard the filled primer fluid drain cartridges.
• Obey the local laws and regulations regarding the disposal of items such as the primer fluid
drain cartridges.
If Draining Fails to Start
If one or more of the ID chips on the drain cartridges is damaged, the operation may not start. Even if
you set SP2-100-004 (Special Maintenance: Extract Filling Liquid) to "31", the fluid will not drain from
the tubes, ink sub tanks, and print heads.
• SP2-100-004
• Press [EXECUTE] to drain the primer fluid from the print heads, print head sub tanks, and ink supply
tubing. This is done at installation before the ink cartridges are installed.
• Special cartridges are provided to hold the drained fluid.
• This SP is used only at installation before the print heads are filled with ink.
1. Open SP2-012-001 (Initial Operation Setting) and set it to "3".
• SP2-012-001
• This SP code is used to modify the initial ink filling sequence at installation and after one or
more print heads have been replaced. Every time the machine is turned on, the machine
checks the ink level in each sub tank. If ink is low, then the machine switches on the ink pump
motor(s) to fill the tank(s).
• This SP should always be set to "0" unless there are specific instructions that it should be reset
temporarily.
2. Turn the power OFF.
3. Remove the drain cartridges, and then replace them with the ink starter cartridges.
4. Close the ink cartridge cover.
5. Turn the power ON.
• Ink filling starts.
Main Machine Installation
129
