Cut Length (mm) Cut Tolerance (mm)
to 3000 ±11
to 3600 ±14
to 15,000 ±150
Step 11: Synchro Cut (Trailing Edge Registration)
The following SPs are used in this step:
• SP4-961-001 (Document Length Adjustment – Input Tolerance 210 mm)
• SP4-961-002 (Document Length Adjustment – Input Tolerance 1000 mm)
• SP4-961-003 (Document Length Adjustment – Check Document Length)
1. Prepare two originals
• 1 original 210 mm long (A4 LEF)
• 1 original 1000 mm long (measure and cut)
2. Go into the SP mode and do SP4-961-001.
3. Touch [COPY Window] and copy the 210 mm sheet that you prepared in Step 1.
4. Touch [SP Mode] to go back to the SP mode.
5. Do SP4-961-003 to check the original scan length.
6. If the display is different, adjust with SP4-961-001.
7. Do SP4-961-002.
8. Touch [COPY Window] and scan the 1000 mm sheet that you prepared in Step 1.
9. Touch [SP Mode] to go back to the SP mode.
10. Do SP4-961-003 to check the scan length.
11. If the display is different, adjust with SP4-961-002.
Cut Length (mm) Cut Tolerance (mm)
Less than 297 ±4.50
to 594 ±5.00
to 841 ±6.00
to 1219 ±8.50
to 2000 ±18.0
Special Adjustments
585
