Ricoh MP CW2201 Service Manual

No. Item Q'ty
4. Hex Socket Bolt*
1
8
4. lock washers 8
4. Allen key 1
*1
An Allen key is provided for the hex bolts. One lock washer is provided for each socket bolt.
Installing the Main Unit Stand
• Be sure to attach one lock washer to each hex socket bolt before you fasten the bolt.
2. Installation
68
