2. Cutter switch (left) ( x1, x1, x2).

Cutter Motor

1. Cutter unit (p.369).

2. Loosen the two screws of the cutter unit to release the tension of the timing belt [A].

3. Spring [B] (

x1).

4. Replacement and Adjustment

374
