Page #175 background imageLoading...
Page #175 background image
No. Item Q7ty
6 Plastic screw 4
7 Ferrite core 2
8 Decal: Card reader 1
- Fastener: R/W 2
Installation Guide
• Set the main power switch to OFF and disconnect the power plug from the power outlet before
performing the procedure below. Working with power supplied may cause electrical shock or
defects.
Removing the operation cover
1. Remove the screws on the operation cover ( x2).
2. Release the hooks ( x3).
Controller Options
169
