Ink Cartridge and Ink Collector Tank Replacement
1. Open the ink-cartridge cover, and remove the ink cartridge.
2. Attach the customer's ink cartridge and close the ink-cartridge cover.
3. Open the ink collector tank cover and remove the ink collector tank.
4. Attach the customer's ink collector tank and close the cover.
Carriage Unit
• The screws shown below are adjusted their position at the factory. Never loosen nor remove them
for changing or adjusting.
Forty screws on the backward frame of the main unit (the figure is with the upper cover
removed)
Carriage Unit
465
