• Move the scanner unit and stand assembly carefully. It is top heavy and can tip over easily.

Operation Panel

The work other than removing of the operation panel, refer to the service manual for Smart Operation

Panel.

Remove

1. Remove the screws on the operation cover. ( x2)

2. Release the hooks. ( x3)

Common Procedures
