7. Slowly raise the left side of the scanner unit to put it on the left rear edge of the scanner
rack [A].
8. Insert the cardboard between the left front of the bottom of the scanner unit and the
scanner rack [B].
• The size of the sheet of cardboard inserted between the scanner unit and scanner rack is 10
cm long and 2 cm thick.
Raise the Right Side of the Scanner Unit.
To remove the screw behind the edge of the scanner rack without removing the rack from the scanner
unit, place the scanner unit above the edge of the scanner rack.
4. Replacement and Adjustment
264
