Ricoh MP CW2201 Service Manual

Roll Paper Feed Motor
1. Remove the roll unit (p.314, p.322).
2. Remove the right outer cover, right inner cover, and switch cover (p.342).
The roll paper feed motor [A] is placed at the lower right of the roll unit.
4. Replacement and Adjustment
334
