Safety Switch
1. Remove the scanner rear cover (p.260).
2. Remove the scanner left cover and scanner right cover (p.260).
3. Raise the top of scanner unit to the full upright position (p.254).
4. Remove the original table (p.261).
5. Remove the sensor cover. ( x2)
6. Remove the safety switch with the bracket [A]. ( x1)
4. Replacement and Adjustment
288
