Sensors, Switches
• Set the main power switch to OFF and disconnect the power plug from the power outlet before
performing the procedure below. Working with power supplied may cause electrical shock or
defects.
Ink Collector Tank Cover Switch
1. Right cover (p.239).
2. Ink collector tank cover switch [A] ( x1).
Ink-cartridge Cover Switch
1. Right cover (p.239).
2. Right upper cover (p.241).
3. Ink-cartridge cover (p.243).
Sensors, Switches
573
