Ricoh MP CW2201 Service Manual

5. Align the cut-outs in the frame of the scanner unit with the positioning pins on either end
of the scanner stand.
6. Set the scanner unit on the positioning pins, then fasten the unit to the stand ( x4 hex
socket bolt).
Roll Unit 1 (Standard)
Accessories: Roll Unit 1
Main Machine Installation
81
