Input and Output Check
Input Check Table (SP5-803)
5803 Input Check
1 Paper Inlet Sensor: Upper
2 Paper Inlet Sensor: Lower
3 Paper Exit Sensor: Upper
4 Paper Exit Sensor: Lower
5 Front Register Sensor
6 By-pass Sensor
7 Output Sensor
10 Paper Feed Pressure Release Sensor: Upper
11 Paper Feed Pressure Release Sensor: Lower
12 Register Pressure Release Sensor: Lower
13 Residual Amount. Sensor Upper
14 Residual Amount. Sensor Lower
15 Residual Qty. Ratio M
16 Residual Qty. Ratio Y
17 Main Scan Encoder Sensor
18 Sub Scan Encoder Sensor
19 Roll End Sensor/Upper
20 Roll End Sensor/Lower
21 Front Cover Pre-Sensor
22 Total Counter
23 Separation claw position sensor
3. SP Mode Tables
264
